AP-DJ2814 ap&t industrial overhead anti static esd air ionizer
AP-DJ2814 intelligent control / networking type screen display ion fan using DC de static technology, 4 mouth fan, wide range of de static, high air volume fan five-speed speed regulation, stable performance, the output air volume than ordinary fans to improve 1.45 times. With LCD display, with ion self-balancing function, self-balancing range ± 10V, and real-time display balance voltage.
1.light touch switch button, easy to operate and use, fast.
2.Multiple air outlets, each outlet 8 needles, ion generation large amount.
3.with automatic brush needle function.
4.default every 8 hours automatically brush the needle once, eliminating the need to manually brush the needle cleaning and maintenance.
5.high air volume fan five-speed speed regulation, stable performance, the output air volume than ordinary fans increased by 1.45 times.
6.with LCD display, can display the device address, wind speed gear, cleaning cycle, ion balance voltage, temperature and humidity, high voltage alarm, each wind port balance voltage real-time display, exceed the set threshold alarm; high voltage failure for 0V, the output alarm prompt.
7.with ion self-balancing function, self-balancing range ± 10V, and real-time display of the balance voltage.
8.positive and negative ion output ratio adjustable, can be used to adjust the ion balance voltage.
9.fan failure and ion balance abnormalities, the display and LED red light alarm.
10.ion output characteristics, can be adjusted by remote control.
11.can achieve wired network communication, monitoring the working status of the fan.
12.through the CE test, with electromagnetic protection function, will not cause electromagnetic interference to other equipment; can also effectively avoid external electromagnetic interference affect the normal work of the fan.
13.magnetic mesh cover, mesh cover separation instant power off, the fan then in standby (STOP) state, easy to clean and maintain.
| Model |
AP-DJ2814 |
| Input voltage |
DC 24V(RJ45 interface)/ Three in one socket(220VAC 50/60Hz) |
| Output voltage |
DC±4KV → ±6KV |
| Power |
42.5W |
| Ion emission |
Pulse DC |
| Emitter electrode |
Tungsten alloy |
| Discharge range |
750*1050mm(L*W) |
| Air volume |
≤ 135CFM*4 |
| Noise |
Single air outlet≤ 58dBA(1000mm away from the air outlet) |
| Ozone thickness |
≤ 0.05ppm(150mm away from the air outlet) |
| Ion balance |
≤ |±15V| |
| Discharge speed |
≤ 2.5S(450mm away from the air outlet) |
|
Status indicator |
Power on/clean operation—blue light flashes; |
|
Normal work—green light (always under monitoring status); |
|
|
Fan fault alarm—red light always on; |
|
|
Balance voltage exceed alarm-red light flashes; |
|
|
High voltage fault alarm-red light flashes; |
|
|
Infrared debugging/cleaning prompt-blue light flashing |
|
| Communication method |
RS485 |
|
Signal output |
RS485(115200bps,8,1,n,n)≥ 20ms |
|
Collector open circuit:< 50V,100mA |
|
| Working temperature |
0℃ -50℃ |
| Working humidity |
< 70%RH |
| Dimensions(L*W*H) |
1011*154*70mm(Ionizing Air Blower body size) |
| Shell material |
Aluminum powder spraying |
| Installation accessories |
1 pair of L-shaped iron powder spraying mounting brackets, 1 pair of bakelite screw handles(M5×8) |
|
Power adapter |
INPUT:AC100—240V 50/60Hz; (This is preferred for simultaneous power supply) |
|
OUTPUT:DC24V 2A(dual RJ45 interface) |
|
| Net weight(Including power cord and bracket) |
4.85KG |
| Warranty |
1Year |
| Certification |
CE |
The pulsed DC method alternately applies “+” and “-” high voltage to the positive and negative electrode pins to generate two polar ions. Compared with the industrial frequency AC method, the ion generation utilization rate is higher, whether for close or long distance, can play its electrostatic elimination ability. In addition, the discharge frequency can be adjusted to extend the elimination distance. Positive and negative ion output ratio can be adjusted for intelligent control.
